Shaft Heaters & Insulator Heaters



Shaft Heaters & Insulator Heaters helps to adjust the temperature above dew point withing the range of 80 deg. C to 120 deg C. If the temperature is not maintained at required range there will be constant tracking of electrical field over the surface of insulator, This will damage the insulator and electric field will not be generated to collect fly ash. Heaters can be customized as per ESP designs also.

Product Details

Material

Operating Voltage

Operating Temp.

Thickness



MS, SS and other various components.

220,380,400,415,440,460,480 Volts

Maximum 300 Degree Celsius

7 mm-16 mm

Insulator Heater ESP
ESP Insulator Heater
Hopper Heaters

Heating elements are installed at Hopper. Support & Shaft Insulator plays important role in smooth working of ESP. Ash is collected in hopper at the bottom of ESP, To avoid clinker formation of collected ash inside hopper ESP Hopper Heaters are installed. Hopper are the part of ESP and are installed at bottom of the ESP.
Hopper Heaters helps to generate heat inside hopper to avoid moisture to condensate from getting collected in it Removes fly ash from ESP. Reflector plates can be provided for improved performance of hopper heater. Hopper heaters can be provided with reflector plates for efficient heating in the hopper.



We can provide wide variety of Hopper Heaters i.e. Hopper Heater, Hopper Heater Pad, Stud type Hopper Heater and Panel type, based on requirement.

Product Details

Material

Operating Voltage

Thickness

Operating Temp.



MS , SS or Glass Fiber

220,380,400,415,440,460,480 Volts

As per requirement and depend on heater type

Maximum 300 Degree Celsius

Hopper Heaters
Hopper Heater ESP

Systematic Controls deals in Compatible Products for,

Thermax ESP Spare Parts, ISGEC Esp Spare Parts, Voltas ESP Spare Parts, CVL ESP Spare Parts, Clyde Bergemann ESP Spare Parts, Hamon Research Cottrell ESP Spare Parts, Sitson ESP Spare Parts, Cleair Engineering ESP Spare Parts, ACC ESP Spare Parts, and also ESP Retrofit, ESP Maintenance, ESP Service, ESP Rapper Panel Spare Parts & TR Panel Spare Parts.
